Hardy was the first weighing company to engineer and manufacture PLC Plug-In Weight modules, which are used in applications including: batching/blending, filling/dispensing, check weighing, level by weight, rate control and rate monitoring. Available in single scale or dual scale configurations, the modules transfer clean, accurate weight data directly to the PLC/PAC, which uses its rack I/O for application control. Modules communicate over the backplane of the PLC, which means no other interface or communication wiring, routers or switches are needed, and writing special communications drivers is unnecessary.
Hardy’s modules are the result of long and collaborative relationships with Allen-Bradley® and Rockwell Automation®. Hardy’s proprietary technology was essential in developing the products Allen-Bradley envisioned to meet specific customer needs. Today, Hardy modules are available for Allen-Bradley ControlLogix®, CompactLogix®, Micro800® or SLC500 chassis. Integration is easy with free Add-on Profiles, free Faceplates/AOIs for HMIs and direct backplane connectivity.
• HI 1756-WS and 1756-2WS Single and Dual ControlLogix® Weigh Scale Modules: Released in 2004, these modules mount directly into an Allen-Bradley ControlLogix PLC Chassis to read weight and diagnostic data using a 24-bit A/D converter from one or two separate sets of strain gauge load sensors or load cells and communicate this data over the I/O chassis backplane to the ControlLogix Processor at 100 times per second.
• HI 1769-WS and 1769-2WS CompactLogix® Module: Released in 2000 and 2002 respectively, thes modules read and condition weight and diagnostic data from strain gauge load sensors or load cells using a 24-bit A/D converter up to 100 times per second. They communicate this data over the I/O chassis backplane to the CompactLogix PLC processor. The 1769-WS won ‘Breakthrough Product of the Year’ from Processing Magazine in 2004.
• Easy 8 Micro800 Weigh Scale Module: Released in 2012 and built for the entry-level Allen-Bradley Micro800 programmable controller, Hardy’s Easy 8TM is a low-cost, single channel plug-in module that reads, conditions and digitizes load cell sensor and strain gauge signals commonly found in process weighing applications. Using a 16-bit A/D converter, the Easy 8 updates the controller at 55 times per second
• HI 1769-FC and HI 1756-FC: Released in 2004, Plug-in Loss-in-weight Feeder Control (FC) modules contain field proven algorithms that automatically calculate and adjust tuning parameters required to maintain desired loss-in-weight flow rates. These modules use the PLC/PAC’s rack’s I/O to control a variety of material-flow applications, with auger, belt, or vibratory feeders.
• HI 1756-1DF and HI 1756-2DF: Released in 2010, the HI 1756-nDF ControlLogix Dispenser/Filler modules are the easy answer to a variety of material feed applications, especially, when speed and accuracy of the feed are paramount to the process. The module batches, fills or dispenses aggregates, granulates, liquids or gases, handling the entire feed process.
